Description

Built-in Components: 6 DMIC microphone array, digital PTZ camera, 1 full range ported speaker, cable management & retention system, Multi Mount, integrated motorized privacy shutter, Logitech Collab OS platform | Enclosure: All-in-one enclosure with field replaceable front cover | Device Management: Logitech Sync | Displays Supported: 1 (2nd display support is coming soon) | Display Resolution: 1080p | Network Protocol Support: IPv4, IPv6 | Proxy Support: IP based Proxy, FQDN based Proxy, Proxy using PAC file | Digital Pan: ±48° at 4x zoom | Digital Tilt: ±32° at 4x zoom | Zoom: 4X HD digital zoom | Diagonal Field of View: 120° | Horizontal Field of View: 113° | Vertical Field of View: 80° | Resolution: 4K | Driver: 55 mm with bass reflex enclosure and patented suspension design | Sensitivity: 83 dB SPL @1W +/-2dB @ 1 meter | Rated Power: 8W | THD at 1W, 1kHz: : <2% | Speaker Sampling Rate: 48KHz | Impedance: 4 Ohms | Frequency Response: 90Hz – 16kHz | Sensitivity: -36dBFS +/-1 dB @ 1Pa | Microphone data rate output: 48 kHz | Pickup Range: Up to 7m | Beamforming Elements: Six omnidirectional digital MEMS microphones forming five adaptive acoustic broadside beams | Audio processing: AEC (Acoustic Echo Cancellation), VAD (Voice Activity Detector) | Noise suppression: AI based de-noising algorithm | HDMI Out: : 1 | HDMI In: : 1 | USB: : 1x Type A USB 3.1, 1x Type C USB 3.1 | Network: : 10/100/1G Ethernet | WiFi: : 802.11a/b/g/n/ac | Bluetooth: : Bluetooth® Low Energy | Power supply: Auto-sensing | Operating Voltage/Power: 100-240V, 19V, 2.1A | Power Supply Dimensions: 114 mm x 47 mm x 32.3 mm | DC Cable: 1.5 m | AC Cable: 1 m | HDMI 1.4 Cable: 2 m | USB A to USB C 3.0 Cable: 2.2 m | Operating Temperature: 0 to 40°C | Storage Temperature: -25 to 70°C | Humidity: 10 to 90% | File Based Encryption: : AES-128 | Data Encryption: : Symmetric Keys, PKI | Device Identity: : Protected by device attestation | Device Access: : Authenticated using API | Key Protection: : Arm TrustZone, RPMP | Covers: Rally Bar Huddle Front Cover-Cleanable, Off-White Fabric | Mounts: Wall Mount for Video Bars, TV Mount for Video Bars | Touch Controller: Logitech Tap and Tap IP
