Description

Microsoft Teams Rooms on Android: 1 For small sized rooms | Microsoft Teams Rooms on Windows: 2 For small sized rooms | Built-in Components: : 6 beamforming microphones, PTZ camera, 3 speakers, AI Viewfinder, cable management and retention system, table stand, Logitech CollabOS platform | Enclosure: : All-in-one enclosure with integrated table stand and patented speaker suspension system to eliminate vibration-induced camera shake and audio interference | Device Management: : Logitech Sync | Displays Supported: : 2 | Display Resolution: : Up to 1080p | Network Protocol Support: : IPv4, IPv6 | Proxy Support: : IP based Proxy, FQDN based Proxy, Proxy using PAC file | Resolution: : 4K, 1440p, 1080p, 900p, 720p, and SD at 30fps | Pan: : Motorized ±25° | Tilt: : Motorized ±15° | Zoom: : 4X HD digital zoom | Diagonal Field of View: : 120° | Horizontal Field of View: : 113° | Vertical Field of View: : 80.7° | Total Room Coverage (field of view + pan and tilt): : 163° horizontal x 110° vertical | Driver: : 70 mm | Sensitivity: : 92dB SPL @1W, 99dB SPL @8.0W, both +/-2dB at ½ meter | Rated Power: : 8W | THD: : 1kHz < 2% at 1W | Speaker Sampling Rate: : 48KHz | Impedance: : 4 Ohms | Drivers: : 2 x 43mm | Sensitivity: : 84 dB SPL @ 1W/1M | Rated Power: : 4W | Frequency Response: : 90Hz – 16kHz | Sensitivity: : >-36dBFS +/-1 dB @ 1Pa | Microphone data rate output: : 48 kHz | Pickup Range: : Up to 7 m | Beamforming Elements: : 6 omnidirectional digital MEMS microphones forming 5 adaptive acoustic broadside beams | Audio processing: : AEC (Acoustic Echo Cancellation), VAD (Voice Activity Detector) | Noise suppression: : AI based de-noising algorithm | Add-on Mics: : Supports up to 3 additional Rally Mic Pods and 2 Rally Mic Pod Hubs for larger conference rooms | RightLight: : Renders natural skin tones for each participant | RightSight: : Primary camera frames the active speaker while the AI Viewfinder captures everyone in the room | RightSound: : Distinguishes speech from other sounds to auto-level voices while suppressing background noise and echo | Grid View: : Detects and frames all meeting participants in order to create equitable hybrid meeting experiences. To learn more, visit logitech.com/prosupport/gridview | HDMI Out: : 2 (up to 1080p) | HDMI In: : 1 | USB: : 3x Type A, 1x Type C | Network: : 10/100/1G Ethernet | WiFi: : 802.11a/b/g/n/ac | External Mic Input: : Yes (proprietary input supports optional Rally Mic Pod, Rally Mic Pod Hub, and Rally Mic Pod Extension Cable) | Remote Control: : Bluetooth® Low Energy | Power supply: : Auto-sensing | Operating Voltage/Power: : 100-240V, 19V, 4.74A | Power Supply Dimensions: : 127 mm x 51 mm x 30 mm | DC Cable: : 1.5 m | AC Cable: : 1 m | HDMI 1.4 Cable: : 2 m | USB A to USB C 3.0 Cable: : 2.2 m | Operating Temperature: : 0 to 40°C | Storage Temperature: : -40 to 70°C | Humidity: : 10 to 95% | BTU/hr: : 57 idle, 64 in meeting | Full Disk Encryption: : AES-128 | Data Encryption: : Symmetric Keys, PKI | Device Identity: : Protected by device attestation | Device Access: : Authenticated using API | Key Protection: : Arm TrustZone, RPMP | Mounts: : Wall Mount for Video Bars, TV Mount for Video Bars | Audio: : Rally Mic Pod, Rally Mic Pod Hub, Rally Mic Pod Mount, Rally Mic Pod Extension Cable | Connectivity: : Logitech Strong USB (10m, 25m, 45m) | Touch Controller: : Logitech Tap and Tap IP 3 Compatibility may vary, see www.logitech.com/support/tap-compatibility for the latest information
