Description

Features: HPE ProLiant Compute DL320 Gen12 | Server Type / Form Factor: Type: Enterprise Rack Server Form Factor: 1U Rack Socket: Single-socket (1 x Intel Xeon 6 P-core processor) | Processor (CPU): Processor Family: Intel Xeon 6 (Rich I/O P-core series) Max Sockets: 1 Max Cores per Socket: Up to 144 cores Max TDP: Up to 350 W (varies by CPU model) Memory Channels: 8 channels per processor | Memory (RAM): Memory Type: HPE DDR5 Smart Memory (RDIMM) DIMM Slots: 16 DIMM slots Maximum Capacity: Up to 4 TB (with 256 GB modules) Speed: Up to 6400 MT/s memory (1DPC) Protection: ECC and advanced RAS features | Storage: Drive Bays (Front): Up to 20 EDSFF E3.S NVMe drive bays SFF Options: 2 SFF x4 Tri-Mode 24G U.3 BC drive cages Backplane Options: 8 SFF x1 or x4 Tri-Mode 24G U.3 BC backplanes Boot Options: Optional NS204i-u Hot-Plug Boot Device (front or rear) Storage Controllers: HPE OCP-type RAID (OROC) or PCIe-based controllers | Expansion / Connectivity: PCIe Slots: Multiple PCIe 5.0 x16-style slots (primary and secondary riser configuration) OCP Slots: Front or rear OCP 3.0 networking slots (1 Gb / 10 Gb / higher options) GPU Support: Up to four single-wide GPUs or two double-wide GPUs (configuration dependent) Ports / I-O: USB 3.2 Gen1 front ports Video Options: Optional DisplayPort / VGA via DC-SCM Management Port: Dedicated iLO service port | Redundancy & Reliability: Power: Modular Common Redundant Power Supply (M-CRPS) design; redundant hot-plug power supplies optional Cooling: Integrated system fan array (7 fans) with hot-swap capability Availability Features: DC-MHS-based hot-swap components, quick-removal access panel, and enterprise-grade serviceability | Operating System Support: Microsoft Windows Server Red Hat Enterprise Linux (RHEL) SUSE Linux Enterprise Server (SLES) VMware ESXi Canonical Ubuntu Oracle Linux | Security Features: HPE iLO 7 security and secure boot Intel-based hardware security (P-core protections and Rich I-O options) UEFI-managed firmware integrity and TPM-class key management Data-at-rest protection via HPE-approved self-encrypting and encrypted-drive options | Management & Monitoring: HPE iLO 7: Remote console, firmware updates, and configuration Redfish API: Support for orchestration and integration HPE Tools: Cloud operating experience and modular hardware-management capabilities | Warranty & Support: Standard Warranty: 3 Years Parts, 3 Years Labor, 3 Years Onsite (region- and contract-dependent) Optional Support: HPE Pointnext services, Foundation Care, Proactive Care, and custom SLAs for edge, SMB, and ROBO deployments | Certified Quality: – 100% genuine HPE servers with official warranty for reliable performance. | Optimized Rack Efficiency: – Compact 1U design with Intel® Xeon® processors and DDR5 memory. | Expandable Storage: – NVMe and SAS drive for flexible growth as your business scales. | Proactive Management: – Advanced HPE iLO tools for monitoring and secure remote access. | Continuous Support: – Prompt technical assistance, upgrades, and maintenance whenever needed. | Reliable Delivery: – Quick responses and Prompt delivery across the UAE, Middle East, and Africa. | Type: Server Type / Form Factor Enterprise Rack Server Form Factor: 1U Rack Socket: Single-socket (1 x Intel Xeon 6 P-core processor) | Type: Enterprise Rack Server | Form Factor: 1U Rack | Socket: Single-socket (1 x Intel Xeon 6 P-core processor) | Processor Family: Processor (CPU) Intel Xeon 6 (Rich I/O P-core series) Max Sockets: 1 Max Cores per Socket: Up to 144 cores Max TDP: Up to 350 W (varies by CPU model) Memory Channels: 8 channels per processor | Processor Family: Intel Xeon 6 (Rich I/O P-core series) | Max Sockets: 1 | Max Cores per Socket: Up to 144 cores | Max TDP: Up to 350 W (varies by CPU model) | Memory Channels: 8 channels per processor | Memory Type: Memory (RAM) HPE DDR5 Smart Memory (RDIMM) DIMM Slots: 16 DIMM slots Maximum Capacity: Up to 4 TB (with 256 GB modules) Speed: Up to 6400 MT/s memory (1DPC) Protection: ECC and advanced RAS features | Memory Type: HPE DDR5 Smart Memory (RDIMM) | DIMM Slots: 16 DIMM slots | Maximum Capacity: Up to 4 TB (with 256 GB modules) | Speed: Up to 6400 MT/s memory (1DPC) | Protection: ECC and advanced RAS features | Drive Bays (Front): Storage Up to 20 EDSFF E3.S NVMe drive bays SFF Options: 2 SFF x4 Tri-Mode 24G U.3 BC drive cages Backplane Options: 8 SFF x1 or x4 Tri-Mode 24G U.3 BC backplanes Boot Options: Optional NS204i-u Hot-Plug Boot Device (front or rear) Storage Controllers: HPE OCP-type RAID (OROC) or PCIe-based controllers | Drive Bays (Front): Up to 20 EDSFF E3.S NVMe drive bays | SFF Options: 2 SFF x4 Tri-Mode 24G U.3 BC drive cages | Backplane Options: 8 SFF x1 or x4 Tri-Mode 24G U.3 BC backplanes | Boot Options: Optional NS204i-u Hot-Plug Boot Device (front or rear) | Storage Controllers: HPE OCP-type RAID (OROC) or PCIe-based controllers | PCIe Slots: Expansion / Connectivity Multiple PCIe 5.0 x16-style slots (primary and secondary riser configuration) OCP Slots: Front or rear OCP 3.0 networking slots (1 Gb / 10 Gb / higher options) GPU Support: Up to four single-wide GPUs or two double-wide GPUs (configuration dependent) Ports / I-O: USB 3.2 Gen1 front ports Video Options: Optional DisplayPort / VGA via DC-SCM Management Port: Dedicated iLO service port | PCIe Slots: Multiple PCIe 5.0 x16-style slots (primary and secondary riser configuration) | OCP Slots: Front or rear OCP 3.0 networking slots (1 Gb / 10 Gb / higher options) | GPU Support: Up to four single-wide GPUs or two double-wide GPUs (configuration dependent) | Ports / I-O: USB 3.2 Gen1 front ports | Video Options: Optional DisplayPort / VGA via DC-SCM | Management Port: Dedicated iLO service port | Power: Redundancy & Reliability Modular Common Redundant Power Supply (M-CRPS) design; redundant hot-plug power supplies optional Cooling: Integrated system fan array (7 fans) with hot-swap capability Availability Features: DC-MHS-based hot-swap components, quick-removal access panel, and enterprise-grade serviceability | Power: Modular Common Redundant Power Supply (M-CRPS) design; redundant hot-plug power supplies optional | Cooling: Integrated system fan array (7 fans) with hot-swap capability | Availability Features: DC-MHS-based hot-swap components, quick-removal access panel, and enterprise-grade serviceability | HPE iLO 7: Management & Monitoring Remote console, firmware updates, and configuration Redfish API: Support for orchestration and integration HPE Tools: Cloud operating experience and modular hardware-management capabilities | HPE iLO 7: Remote console, firmware updates, and configuration | Redfish API: Support for orchestration and integration | HPE Tools: Cloud operating experience and modular hardware-management capabilities | Standard Warranty: Warranty & Support 3 Years Parts, 3 Years Labor, 3 Years Onsite (region- and contract-dependent) Optional Support: HPE Pointnext services, Foundation Care, Proactive Care, and custom SLAs for edge, SMB, and ROBO deployments | Standard Warranty: 3 Years Parts, 3 Years Labor, 3 Years Onsite (region- and contract-dependent) | Optional Support: HPE Pointnext services, Foundation Care, Proactive Care, and custom SLAs for edge, SMB, and ROBO deployments | Edge Computing Environments: Compact server ideal for distributed and edge deployments. | Virtualization Workloads: Efficient platform for running multiple virtual machines. | Cloud and Hosting Providers: High-density computing suitable for service provider infrastructure. | Power-Constrained Data Centers: Optimized performance in environments with limited power capacity. | Enterprise Applications: Reliable infrastructure for business-critical applications. | Space-Constrained Racks: 1U form factor maximizes rack utilization in modern data centers. | Socket: Single-socket (1 x Intel Xeon 6 Processor) | Processor Family: Intel Xeon 6 (E-core or P-core series) | Max Cores: Up to 144 E-cores or 86 P-cores | Max TDP: Up to 330W (Sierra Forest SRF) | PCIe Lanes: 88 PCIe Gen5 lanes per CPU | Memory Type: DDR5 RDIMM (registered ECC only) | DIMM Slots: 16 DDR5 DIMM slots | Maximum Capacity: Up to 4 TB | Speed: Up to 6400 MT/s | Protection: ECC with advanced RAS features | Front Drive Bay Options: Up to 8 x E3.S NVMe SSD | Configuration Option: Up to 8 x 2.5-inch SAS/SATA/Nearline SAS/NVMe | Boot Optimization: NVMe BOSS (Boot Optimized Server Storage) | RAID Support: PERC H965i/H365i controllers (RAID 0, 1, 5, 6, 10, 50, 60) | PCIe Slots: Up to 2 x16 Gen5 PCIe slots (riser configuration) | Networking: OCP 3.0 (1/10/25 GbE options) | GPU Support: GPU-enabled configurations available | I/O Options: Rear I/O (hot aisle) or Front I/O (cold aisle) | Power: Redundant hot-plug PSUs (800W Platinum, 1500W Titanium) | Cooling: Redundant hot-swap fans; advanced cooling options | Reliability: Hot-swap components, tool-less serviceability | iDRAC10 Enterprise: Embedded remote management | Dell OpenManage Enterprise: AI-driven management | APIs: Redfish APIs for automation and orchestration | Standard Warranty: 3 Years ProSupport (parts, labor, onsite) | Optional Support: ProSupport Plus, ProSupport Enterprise, extended terms
