Description

Features: ThinkSystem SR630 V4 | Server Type / Form Factor: Type: Enterprise Rack Server Form Factor: 1U Rack Socket: Dual-socket (2x Intel Xeon 6 processors) | Processor (CPU): Processor Family: Intel Xeon 6 (6700/6500 P-cores & E-cores) Max Sockets: 2 Max Cores: Up to 288 cores total (144 E-cores/socket) Max TDP: Up to 350 W (P-cores), 330 W (E-cores) Max Speed: Up to 4.0 GHz (P-cores) | Memory (RAM): Memory Type: TruDDR5 (RDIMM, 3DS RDIMM, MRDIMM) DIMM Slots: 32x RDIMMs + 16x MRDIMMs Maximum Capacity: Up to 8 TB Speed: 6400 MHz (RDIMM), 8000 MHz (MRDIMM) Protection: Advanced ECC, RAS features | Storage: Front Drive Bays: 10x 2.5″ SAS/SATA/NVMe or 4x 3.5″ bays Max Internal Storage: 368.64 TB (16x 15.36 TB NVMe SSDs) Onboard NVMe: Up to 16x NVMe ports (Intel VROC RAID) RAID Support: Intel VROC NVMe RAID (0,1,5,10), PCIe RAID/HBA | Expansion / Connectivity: PCIe Slots: Up to 5x PCIe Gen5 slots OCP Slots: 2x OCP 3.0 (x8, cabled x16) Networking: 10/25/100 GbE OCP adapters GPU Support: Up to 3x SW 75W GPUs | Redundancy & Reliability: Power: Dual redundant AC/DC PSUs (800W, 1300W, 2000W Platinum/Titanium) Cooling: Lenovo Neptune Core/Air, redundant fans Reliability: Six nines uptime, hot-swap components | Operating System Support: Microsoft Windows Server Red Hat Enterprise Linux (RHEL) SUSE Linux Enterprise Server (SLES) VMware ESXi Ubuntu Server | Security Features: Lenovo ThinkShield security suite Silicon Root of Trust Secure Boot and fTPM 2.0 Runtime Firmware Resilience | Management & Monitoring: XClarity Controller 3: Embedded management XClarity Enterprise: AI-driven analytics APIs: Redfish APIs for automation | Warranty & Support: Standard Warranty: 3 Years CRU/Onsite NBD 9×5 Optional Support: Premier Support, TruScale services | Dependable Performance: – We ensure your server runs virtualization, databases, and critical business applications without slowdowns. | Tailored Server Configuration: – Receive guidance to select the right processor, memory, and storage setup for your specific workloads. | Scalable Infrastructure: – Expand memory and storage easily as your business grows, keeping your IT environment future-ready. | Seamless Deployment: – We provide step-by-step guidance to make installation and integration with your existing systems effortless. | Reliable Support & Delivery: – Fast product availability, prompt delivery, and ongoing assistance help maintain smooth server operations. | Type: Server Type / Form Factor Enterprise Rack Server Form Factor: 1U Rack Socket: Dual-socket (2x Intel Xeon 6 processors) | Type: Enterprise Rack Server | Form Factor: 1U Rack | Socket: Dual-socket (2x Intel Xeon 6 processors) | Processor Family: Processor (CPU) Intel Xeon 6 (6700/6500 P-cores & E-cores) Max Sockets: 2 Max Cores: Up to 288 cores total (144 E-cores/socket) Max TDP: Up to 350 W (P-cores), 330 W (E-cores) Max Speed: Up to 4.0 GHz (P-cores) | Processor Family: Intel Xeon 6 (6700/6500 P-cores & E-cores) | Max Sockets: 2 | Max Cores: Up to 288 cores total (144 E-cores/socket) | Max TDP: Up to 350 W (P-cores), 330 W (E-cores) | Max Speed: Up to 4.0 GHz (P-cores) | Memory Type: Memory (RAM) TruDDR5 (RDIMM, 3DS RDIMM, MRDIMM) DIMM Slots: 32x RDIMMs + 16x MRDIMMs Maximum Capacity: Up to 8 TB Speed: 6400 MHz (RDIMM), 8000 MHz (MRDIMM) Protection: Advanced ECC, RAS features | Memory Type: TruDDR5 (RDIMM, 3DS RDIMM, MRDIMM) | DIMM Slots: 32x RDIMMs + 16x MRDIMMs | Maximum Capacity: Up to 8 TB | Speed: 6400 MHz (RDIMM), 8000 MHz (MRDIMM) | Protection: Advanced ECC, RAS features | Front Drive Bays: Storage 10x 2.5″ SAS/SATA/NVMe or 4x 3.5″ bays Max Internal Storage: 368.64 TB (16x 15.36 TB NVMe SSDs) Onboard NVMe: Up to 16x NVMe ports (Intel VROC RAID) RAID Support: Intel VROC NVMe RAID (0,1,5,10), PCIe RAID/HBA | Front Drive Bays: 10x 2.5″ SAS/SATA/NVMe or 4x 3.5″ bays | Max Internal Storage: 368.64 TB (16x 15.36 TB NVMe SSDs) | Onboard NVMe: Up to 16x NVMe ports (Intel VROC RAID) | RAID Support: Intel VROC NVMe RAID (0,1,5,10), PCIe RAID/HBA | PCIe Slots: Expansion / Connectivity Up to 5x PCIe Gen5 slots OCP Slots: 2x OCP 3.0 (x8, cabled x16) Networking: 10/25/100 GbE OCP adapters GPU Support: Up to 3x SW 75W GPUs | PCIe Slots: Up to 5x PCIe Gen5 slots | OCP Slots: 2x OCP 3.0 (x8, cabled x16) | Networking: 10/25/100 GbE OCP adapters | GPU Support: Up to 3x SW 75W GPUs | Power: Redundancy & Reliability Dual redundant AC/DC PSUs (800W, 1300W, 2000W Platinum/Titanium) Cooling: Lenovo Neptune Core/Air, redundant fans Reliability: Six nines uptime, hot-swap components | Power: Dual redundant AC/DC PSUs (800W, 1300W, 2000W Platinum/Titanium) | Cooling: Lenovo Neptune Core/Air, redundant fans | Reliability: Six nines uptime, hot-swap components | XClarity Controller 3: Management & Monitoring Embedded management XClarity Enterprise: AI-driven analytics APIs: Redfish APIs for automation | XClarity Controller 3: Embedded management | XClarity Enterprise: AI-driven analytics | APIs: Redfish APIs for automation | Standard Warranty: Warranty & Support 3 Years CRU/Onsite NBD 9×5 Optional Support: Premier Support, TruScale services | Standard Warranty: 3 Years CRU/Onsite NBD 9×5 | Optional Support: Premier Support, TruScale services | High-Density Data Centers: Compact 1U design maximizes compute performance per rack. | Cloud Service Providers: Efficient platform for scalable cloud infrastructure. | High-Performance Computing (HPC): Suitable for modeling, simulation, and complex computational workloads. | Telecommunications Infrastructure: Reliable platform for 5G core network applications. | Enterprise Applications: Strong compute capabilities for business-critical workloads. | Data Analytics and Web Transactions: Optimized for high-speed data processing and web services. | Socket: Dual-socket (supports 1 or 2 Intel Xeon 6 processors) | Processor Family: Intel Xeon 6 Scalable Processors | Cores per Socket: Up to 144 cores | Max Speed: Up to 4.0 GHz (varies by processor model) | Memory Channels: 8 channels per processor | Memory Type: HPE DDR5 Smart Memory (RDIMM) | DIMM Slots: 32 DIMM slots (16 per processor, 2 DIMMs per channel) | Maximum Capacity: Up to 8 TB (with 256 GB modules) | Speed: Up to 6400 MT/s at 1DPC, 5200 MT/s at 2DPC (processor dependent) | Memory Protection: ECC, On-Die ECC, and advanced RAS features | Front Drive Options: Up to 10 SFF bays (SAS/SATA/NVMe) | EDSFF Options: Up to 20 EDSFF E3.S NVMe bays | Integrated Boot: Integrated OS boot device and OCP NICs in front cage | Max Internal Storage: Multi-hundred TB (depending on drive type and configuration) | RAID Support: HPE Smart Array controllers (RAID 0, 1, 5, 6, 10, 50, 60 – depending on controller) | PCIe Slots: Up to 3 PCIe 5.0 x16 full-height, full-length slots | OCP Slots: 2 OCP 3.0 front slots for high-speed NICs or accelerators | Networking: OCP 3.0 FlexibleLOM (choices of 1/10/25/100GbE) | GPU Support: Up to three single-wide GPUs in rear | Power: Redundant hot-plug power supplies (various wattages and efficiency grades) | Cooling: Redundant hot-plug fans; optional closed-loop or direct-liquid cooling options | Storage: Hot-swap drive bays and RAID-based redundancy | Availability: HPE-engineered reliability and enterprise-grade service-ready design | HPE iLO 7: Embedded management for remote console, BIOS tuning, firmware updates, and alerts | HPE Compute Ops Management: AI-driven insights and lifecycle automation | APIs: RESTful / Redfish-based interfaces for third-party tools | Standard Warranty: 3 Years Parts, 3 Years Labor, 3 Years Onsite (varies by region and contract) | Optional Support: HPE Pointnext, Foundation Care, Proactive Care, and custom SLAs
